XDS Under Vehicle System

The Under Vehicle Surveillance System (UVSS) is designed to enhance surveillance capability by aiding users in scrutinizing the undercarriages of all types of vehicles in seconds.

The system includes a Ramp Observation Unit and a Portable Receiving Unit. It can be dismantled into multiple sections for easy transportation and storage.

The Ramp Observation Unit consists of two side ramps with built-in cameras and LED lights. This unit should be attached to a rubber mat and placed on the ground for temporary use. For long term or permanent installations, the unit can be bolted to the ground. Upon activation, the cameras automatically transmit the video signals to the Receiving Unit. The Portable Receiving Unit is contained in a rugged sealed briefcase. It includes fiveLCD monitors, digital recorder and controller. The video images are automatically recorded and displayed on the LCD monitors with date and time signatures.

UVSS is easy to use and requires minimal training. Controller features include on/off of all devices, rewind/forward of recording for verification or slow motion replay. Effective and efficient, the system enables users to conduct quick and thorough inspections of vehicles entering the premises.

Technical Specifications:

Ramp Observation Unit (ROU)
Camera Type Colour
  Image Sensor ¼” interline transfer CCD
  Resolution 470 lines
  S/N Ratio 47 dB
  Sensitivity 1 lux
  Electronic Shutte Automatic
  Power Supply 12 VDC
  Power Consumption 20 mA
  Lens 2 to 6 mm
  Field of View 70o
Light Type LED
Dimension Side Ramp 100 x 50 x 10 cm
  Ramp Observation Unit 87 x 11 x 8 cm
  Overall View 150 x 50 x 10 cm
Material   Mild Steel
Environmental   IP 65 rated
Portable Receiving Unit (PRU)
LCD Monitors   6.4” x 4 units, 10” x 1 unit
Digital Video Recorder (DVR) Compression Wavelet
  Hard Disk Storage 36, 50 or 100 GB
  Features Record/Play/Fast Forward/Fast Reverse/
Freeze Frame
  Fast/Slow Motion 0 to 16 time Forward/Reverse
Remote Control   87 x 11 x 8 cm
Battery   4 x 12V 7AH rechargeable battery
Dimension   31 ½” x 20 ¾” x 11 ½”
Weight   Approx 25 kg
Operating Hours   Approx 3 hours continuous
Connector   Amphenol (mil specs)
Environmental   IP 65 rated
