XDS Product

Technical Specifications: (33 Master Detector)

Dimensions	Interior Height: 2010 mm
	Exterior Height: 2210 mm
	Interior Width: 760 mm
	Exterior Width: 880 mm
	Depth: 560 mm
Shipping Dimensions	Height: 560 mm
	Width:930 mm
	Depth: 190 mm
Weight	56 kg
Shipping Weight	71 kg
AC supply Voltage	85 to 265 volts AC
AC Supply frequency	47 to 63 Hertz
DC Backup	12 volts 7AH battery giving 4 hrs (typical)
Power consumption	Less than 50W while charging backup battery
Magnetic Field Strength	Complies to NIJ0601.02
Operating Temperature	0deg to 50deg C
Operating Humidity	0% to 95% non-condensing
Optical Gating	Digitally selectable, also used for traffic counting
Intererence Rejection	Analogue noise filtering, Digital Signal Processing, RFI EMI filters, Built in shield
Displays	Backlit LCD display, Target LEDs, Pacing LEDs, red and green, 10 segment level display, Battery operation/battery low LED
Audible Alarm	with digital volume control (adjustable and locable)
Memory	EEPROM based non-volatile backup memory, stores all program settings and configurations, Typical data retention 100 years
User interface	Two level password protected keypad interface, all settings are accessible via 12 key kepad
Security	Software selectable protection of volume and power off, software selectable minimum alarm volume, tamper alarms if keypad is used incorrectly or if optical sensor is disabled, 6 digit administrator password, 4 digit user password (maximm of 10), key access to electronics
Sensitivity	1 to 100 settings, NILEC levels 1 o 5
